Manufacturers, Suppliers and Exporters of Concrete Batching Plant

Concrete Batching Plant

Vinayak Equipments is one of the largest Manufacturer, Supplier and Exporter of Concrete Batching Plant from India. A Concrete Batching Plant is a machine to make Concrete from its fixings viz Cement, Crushed Stone, Sand, Water and Admixture Chemicals. The Concrete Batching Plant stands as the heartbeat of construction projects, providing a centralized hub for the precise mixing of concrete components.

Concrete Batching Plant Manufacturer

This technological marvel streamlines the production process, ensuring a consistent and high-quality concrete output. Equipped with sophisticated controls, the Concrete Batching Plant allows for meticulous adjustment of mix proportions, catering to diverse project specifications. Its modular design facilitates easy customization and expansion, adapting seamlessly to the evolving needs of construction endeavours. The Concrete Batching Plant’s efficiency not only enhances productivity but also minimizes waste, making it an eco-friendly choice in the construction landscape. With its reliable performance and ability to meet stringent quality standards, the Concrete Batching Plant emerges as an indispensable cornerstone for modern construction, laying the foundation for sturdy and enduring structures. We also offer customized solutions at market leading prices.

Features of Mobile Asphalt Batch Mix Plant

  • Compact Design & Robust Construction
  • User-Friendly Interface
  • Storage and Conveying System
  • Quality Control Tools
  • Heating and Cooling Systems


Technical Specification of Concrete Batching Plant

Sr No. Detail CBP - 45 CBP - 60 CBP - 75
1 Concrete Theoretical Output/hour
(under ideal a. continuous operation condition)
45 cum 60 cum 75 cum
2 Aggregate Storage Bins (3 nos.)
One .In (send) Egli,Op. with Vtirator
lnline Compartment
Type-Bins. 4nos
lnline Compartment
Type-Bins. 4nos
lnline Compartment
Type-Bins. 4nos
3 Aggregate Charging Conveyor System
(In order to provide accurate Charging of the materials)
Weighing-System Equipped  with ElectroMagnetic.
S. type Load Cell.
4 nos 4 nos 4/5/nos
4 Charging Hopper YES YES YES
5 Charging Conveyor Chevron type/Deep
Bucket (optional)
Chevron type/Deep
Bucket (optional)
Chevron type/Deep
Bucket (optional)
6 Mixer Unit Twin Shaft (0.75 M3) Twin Shaft (1 M3) Twin Shaft (1.5 M3)
7 Cement/Filler Weighing System YES YES YES
   Electromagnetic 'S. type load cell 3 nos  4 nos  4 nos
8 Cement Vibrator YES YES YES
9 Water Weighing System YES YES YES
Electromagnetic 'S. Type load cell 1 nos  1 nos  1 nos
10 Admixer Weighing Systern YES YES YES
Electromagnetic 'S. type Load Cell 1 nos  1 nos  1 nos
11 Water Sprinkling/Gravity Discharge YES YES YES
12 Maximum Aggregate Size 60 MM 80 MM 80 MM
13 Cement Filling Hopper YES YES YES
  Capacity 1  cum 1  cum 1  cum
14 Cement Screw Conveyor WAM Make WAM Make WAM Make
15 Air Cornpressor 5 HP 5 HP 5 HP
16 Control Systern Automatic PLC Automatic PLC Automatic PLC
17 Discharge Hopper YES YES YES
18 Discharge Height 4 MTR 4 MTR 4 MTR
